High Silica Double-Sided Gray Silicone Coated Fabric
High Silica Double-Sided Silicone Fabric represents a premium grade composite textile designed for rigorous thermal and industrial environments. Utilizing a highly stable high-silica ceramic fiber carrier uniformly impregnated with advanced silicone resin on both faces, this material delivers exceptional thermal stability, superior dielectric properties, and robust mechanical resilience. Certified to Class A2 flame retardancy and manufactured with precise dimensional control (0.52 mm ±0.02 mm), it exhibits outstanding bidirectional tensile resistance (Warp: 1223.9 N/50mm / Weft: 1259.4 N/50mm). Its flawless, wrinkle-free surface ensures reliable sealing performance, weather resistance, and long-term structural integrity across demanding commercial and technical applications.
Basic Info.
| Model NO. | 1550-530 | ||
| Double-Sided Silicone Coating | 0.52 mm | ||
| High Silica Carrier Fabric + Silicone Resin | |||
| 533.6 g/m² | 402.5 g/m² | ||
| 131.1 g/m² (~24.6%) | 0.52 mm | ||
Plastic Wrap + Core Tube + Carton/Pallet |
|||
|
|
|||
| Class A2 | 1223.9 N/50mm | ||
| 1259.4 N/50mm |
High-temperature furnace linings & flexible expansion joints
Protective gear, filtration media & chemical-resistant bags
Delivering precision-engineered silicone composite fabrics for critical thermal and safety applications.
Certified to Class A2 fire retardant standards, this high-silica composite effectively resists ignition and prevents flame propagation without melting or toxic smoke emission, ensuring maximum workplace and facility safety.
Engineered with a densely woven high-silica carrier, achieving warp tensile strength of 1223.9 N/50mm and weft strength of 1259.4 N/50mm. Delivers unmatched resistance to tearing, stretching, and operational fatigue under heavy loads.
Precision Dual-Side Saturation
Utilizes a controlled impregnation process applied uniformly to both surfaces, optimizing silicone content at ~24.6% for enhanced chemical resistance, dielectric stability, and consistent flexibility across complex installations.
Manufactured under strict national testing protocols (JC/T170-2012 & GB/T7689.5-2013), guaranteeing exact thickness tolerance (0.52±0.02 mm) and flawless surface integrity free from wrinkles or exposed fibers.
Ideal for demanding sealing, insulating, and protective roles across HVAC, automotive, petrochemical, and manufacturing sectors where thermal stability and structural reliability are paramount.
| Waterproof plastic wrap + core tube + outer carton/pallet | |
| 7-20 (days) depending on order volume |
